EVH 5150 Series Deluxe Poplar Burl Ebony Fingerboard Aqua Burst (357)

Engineered for speed, comfort and full-throttle attitude, the reimagined 5150™ Series Deluxe is an iconic blast from the past that blends both throwback and modernized features.

Like its predecessor, the 5150 Deluxe Poplar Burl features a modified Strat®-style basswood body with a deeper upper body curve. The graphite-reinforced bolt-on quartersawn maple neck features a comfortable modified “C” profile, hand-rubbed satin urethane back finish, heel-mount truss rod adjustment wheel and color matched “hockey stick” headstock with EVH® logo decal. Built for smooth and speedy playability, the 12”-16” compound radius ebony fingerboard has 22 jumbo frets and cream dot inlays.

While the famed striped original had a single humbucking bridge pickup only, the all-new 5150 Deluxe is outfitted with an HH pickup configuration controlled by a three-way toggle on the upper bout. The custom designed EVH® Wolfgang® Alnico 2 humbucking bridge pickup delivers the perfect amount of punch and articulation with sweet sustain and thick chunky rhythms in a perfectly balanced EQ curve. The EVH Wolfgang Alnico 2 humbucking neck pickup serves up no-nonsense, balls to the wall overdrive and endless sustain without skimping on articulate cleans when the volume is rolled down. A custom designed low friction volume knob creates even-volume tapering for the smoothest volume swells, while the high friction tone knob will stay in place even if accidentally bumped. An added new feature comes in the way of a lower bout kill switch, allowing you to mute your guitar for those stutter, rhythmic effects — think “You Really Got Me.”

Body Shape: 5150
Body Material: Basswood
Body Finish: Gloss Urethane
Color: Aqua Burst
Neck Material: Quartersawn Maple
Neck Finish: Hand-Rubbed Satin Urethane
Fingerboard Material: Ebony
Fingerboard Radius: 12"-16" Compound Radius (304.8 mm to 406.4 mm)
Fret Size: Jumbo
Neck Shape: EVH Modified "C" Backshape
Number of Frets: 22
Nut Material: Floyd Rose R3 Locking
Nut Width: 1.685" (42.8 mm)
Tuning Machines: EVH-Branded Gotoh
Position Inlays: Cream Dot
Configuration: HH
Bridge Pickup: Direct Mount EVH Wolfgang Humbucking
Neck Pickup: Direct Mount EVH Wolfgang Humbucking
Switching: 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup
Controls: Volume (500K EVH Bourns Low Friction Pot) with Treble Bleed Circuit, Tone (250K EVH Bourns High Friction Pot)
Control Knobs: Black Knurled with White Indicator
Bridge: Top-Mount EVH-Branded Floyd Rose Locking Tremolo with EVH D-Tuna
Pickguard:
Hardware Finish: Chrome
